Sell your Square D Mini Power-Zone mini power center.
Encapsulated dry-type transformer packaged with primary main breaker, secondary main breaker and a branch circuit interior in one enclosure. Also sold as Square D MPZ, Square D Mini Power-Zone unit substation, Schneider Electric Mini Power-Zone. New surplus, used, or failed. Send the nameplate, get a written offer.
Get an offerWhat it is
The catalog number is on the transformer nameplate inside the enclosure. Photograph the nameplate, the open interior with the main breakers visible, and the outside of the enclosure so we can judge rust and door condition.
| Type | Encapsulated dry-type transformer packaged with primary main breaker, secondary main breaker and a branch circuit interior in one enclosure |
|---|---|
| Manufacturer | Square D, Square D MPZ, Square D Mini Power-Zone unit substation, Schneider Electric Mini Power-Zone |
| On the nameplate | MPZ, MPZB |
| Single-phase | 480 V primary to 120/240 secondary, 10 to 25 kVA in the catalog numbers checked |
| Three-phase | 480 V primary to 208Y/120 secondary, 15 kVA in the catalog numbers checked |
| Insulation and rise | F code: class 180 insulation at 115 C rise |
| Primary main (single-phase) | FAL24060 on the 15 kVA unit, FAL24100 on the 25 kVA unit |
| Secondary main (single-phase) | QO280 on the 15 kVA unit, QO2125 on the 25 kVA unit |
| Enclosure | Type 3R |
| Interrupting rating | 18 kA standard on listed units; 25K suffix marks a 25 kA unit |
How to read a Square D Mini Power-Zone mini power center catalog number.
MPZ is the Mini Power-Zone with a plug-on QO branch interior. MPZB is the bolt-on branch version. Next is the kVA, then S for single-phase or T for three-phase, then a voltage code: 40 is 480 V to 120/240 single-phase and 2 is 480 V to 208Y/120 three-phase on these units. The F that follows is the class 180, 115 C rise insulation code. A trailing 25K marks a 25 kA interrupting rating.
Not sure? Type it into the catalog lookup or text a photo of the label.
- Complete units with both main breakers and the interior intact are worth more than stripped shells.
- Branch breakers left in the interior add value. QO plug-on breakers are common and easy to resell.
- Bolt-on MPZB units and 25 kA versions are less common than the standard MPZ.
- Outdoor units with rusted enclosures still sell for the transformer and breakers.
- We do not publish prices. Metal, demand, and condition move them. You get a written number for your unit.
The Mini Power-Zone is a whole package, so a unit missing its FAL primary main or QO secondary main is quoted as parts. The voltage code on these does not match the general purpose line: a three-phase 480 to 208Y/120 Mini Power-Zone uses 2 where an EE or EXN uses 3. Do not cross-reference the two by code alone. Units pulled from parking lot lighting or temporary power often come back with weathered doors but sound transformers.
Three photos price most Square D Mini Power-Zone mini power center offers.
The label
The catalog number, straight on and in focus. For a pallet, one label per model plus a count.
The unit
Front, sides, and anything damaged. Doors open if it has them.
The lot
The whole pallet or shelf. New in box: the box labels.
Nameplate is on the front cover. For a lot, one nameplate photo per model plus a count and a group shot of the pallet does it.
- 01Send the nameplate
Photos or a list with counts. Text, email, or the form.
- 02We read it and reply
During business hours, by whatever contact method you picked.
- 03You get a written offer
Per unit or per lot. Freight is in the number.
- 04We pick up and pay
Our truck and our rigging. Wire or ACH within 3 business days of a passed inspection.
Freight: Each unit is 100 to 400 pounds. Palletized, banded, liftgate truck. Combine them with anything else you are selling and the freight math improves for both of us.
Selling a Square D Mini Power-Zone mini power center: what people ask.
Yes. We buy them with or without branch breakers. Tell us what is in the interior and send a photo with the cover off.
MPZB is the bolt-on branch version. MPZ units take plug-on QO branch breakers. Both use the same transformer section.
Yes. We still buy the enclosure, interior and breakers, and the transformer goes for core and coil value.
Both. New surplus, used, untested, and failed all sell. Condition sets the number, not whether we buy.
